Built in with an Intel® Quad-Core Celeron® N4100 SoC (2.4 GHz) * Do not disassemble the onboard SoC and the heatsinks by yourself to avoid damage to these components. 2 MB Cache
USB
Integrated in the SoC: 2 x USB 3.1 Gen 1 ports on the back panel 4 x USB 2.0/1.1 ports available through the internal USB headers
BIOS
1 x 128 Mbit flash Use of licensed AMI UEFI BIOS PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
Memory
2 x DDR4 SO-DIMM socket supporting up to 16 GB of system memory Support for DDR4 2400/2133 MHz memory modules (Please refer "Memory Support List" for more information.)
Remark
Due to different Linux support condition provided by chipset vendors, please download Linux driver from chipset vendors' website or 3rd party website.Most hardware/software vendors may no longer offer drivers to support Win9X/ME/2000/XP SP1/SP2. If drivers are available from the vendors, we will update them on the GIGABYTE website.
Storage
Integrated in the SoC: 1 x M.2 connector (Socket 3, M key, type 2280 PCIe x4/x2 SSD support) (M2) 1 x SATA 6Gb/s connector 1 x MSATA connector (MSATA_MPCIE)
Dimensions
14.6cm x 10.2cm
H/W Monitoring
System voltage detection Temperature detection Fan speed detection Fan speed control * Whether the fan speed control function is supported will depend on the cooler you install.
I/O Controller
iTE® I/O Controller Chip
Expansion Slots
1 x M.2 Socket 1 connector for an Intel® wireless module (CNVI) 1 x full size Mini PCIe connector (MSATA_MPCIE) * The MINI_PCIE connector can also be used as an MSATA connector. (The Mini PCIe connector conforms to PCI Express 2.0 standard.)
Unique Features
Support for Xpress Install Support for @BIOS Support for APP Center * Available applications in APP Center may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications
Bundled Software
Norton® Internet Security (OEM version)
Onboard Graphics
Integrated in the SoC: 2 x HDMI ports, supporting a maximum resolution of 4096x2160@60 Hz * Support for HDMI 2.0 version, HDCP 2.2.
Operating System
Support for Windows 10 64-bit
Back Panel Connectors
2 x HDMI port 2 x USB 3.1 Gen 1 ports 2 x RJ-45 ports 1 x audio jacks (Line In, Mic In)
Operating Temperature
0°C to +60°C
Internal I/O Connectors
1 x DC-In power connector 1 x system fan header 1 x SATA 6Gb/s connector 1 x M.2 Socket 3 connector 1 x SATA power connector 1 x front panel header 2 x USB 2.0/1.1 headers 4 x serial port headers 4 x serial port power select jumpers 1 x GPIO header 1 x LVDS header 1 x LVDS drive voltage jumper (LCD_VCC) 1 x flat panel display header (FPD) 1 x flat panel display switch header (MON_SW) 1 x speaker header (SPEAKER) 1 x speaker control header (SPKR_CTRL) 1 x Clear CMOS jumper 1 x I2C jumper 1 x SMBUS jumper
