Built in with an Intel® Quad-Core Celeron® J3455 10W SoC (2.3 GHz) * Do not disassemble the onboard SoC and the heatsinks by yourself to avoid damage to these components. 2 MB Cache
USB
Integrated in the SoC: 2 x USB 3.0/2.0 ports on the back panel 2 x USB 2.0/1.1 ports available through the internal USB headers
BIOS
1 x 128 Mbit flash Use of licensed AMI UEFI BIOS PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
Memory
1 x DDR3L SO-DIMM socket supporting up to 8 GB of system memory Support for DDR3L 1866/1600 MHz memory module (Please refer "Memory Support List" for more information.)
Remark
Due to different Linux support condition provided by chipset vendors, please download Linux driver from chipset vendors' website or 3rd party website.Most hardware/software vendors may no longer offer drivers to support Win9X/ME/2000/XP SP1/SP2. If drivers are available from the vendors, we will update them on the GIGABYTE website.
Storage
Integrated in the SoC: 1 x SATA 6Gb/s connectors 1 x MSATA connector (MSATA_MPCIE)
Dimensions
10.0cm x 7.2cm
H/W Monitoring
Voltage detection Temperature detection
I/O Controller
iTE® I/O Controller Chip
Expansion Slots
1 x M.2 Socket 1 connector for the wireless communication module (M2_WIFI) 1 x full size Mini PCIe slot (MSATA_MPCIE) * The MSATA_MPCIE slot can also be used as an MSATA connector.
Unique Features
Support for Xpress Install Support for @BIOS Support for APP Center * Available applications in APP Center may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications
Bundled Software
Norton® Internet Security (OEM version)
Onboard Graphics
Integrated in the SoC: 1 x HDMI port, supporting a maximum resolution of 3840x2160@30 Hz Maximum shared memory of 512 MB
Operating System
Support for Windows 10 64-bit
Back Panel Connectors
1 x DC In power jack 1 x HDMI port 2 x USB 3.0/2.0 ports 1 x RJ-45 port
Internal I/O Connectors
1 x SATA 6Gb/s connector 1 x SATA power connector 1 x front panel header 1 x flat panel display header 1 x front panel audio header 1 x USB 2.0/1.1 header 1 x serial port header 1 x serial port power select jumper (COM_PW) 1 x LCDVCC/MON header (LCDVCC_MON) 1 x LVDS header 1 x GPIO header 1 x SMBUS 1 x Battery Cable header
