Built in with an Intel® Quad-Core Celeron® N4100 SoC (2.4 GHz) * Do not disassemble the onboard SoC and the heatsinks by yourself to avoid damage to these components. 2 MB Cache
USB
Integrated in the SoC: 4 x USB 3.1 Gen 1 ports on the back panel 4 x USB 2.0/1.1 ports available through the internal USB headers
BIOS
1 x 64 Mbit flash Use of licensed AMI UEFI BIOS PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
Memory
2 x DDR4 SO-DIMM socket supporting up to 16 GB of system memory Dual channel memory architecture Support for DDR4 2133MHz memory module (Please refer "Memory Support List" for more information.)
Remark
Due to different Linux support condition provided by chipset vendors, please download Linux driver from chipset vendors' website or 3rd party website.Most hardware/software vendors may no longer offer drivers to support Win9X/ME/2000/XP SP1/SP2. If drivers are available from the vendors, we will update them on the GIGABYTE website.
Storage
Integrated in the SoC: 2 x SATA 6Gb/s connectors 1 x M.2 connector (Socket 3, M key, type 2242/2260/80 SATA and PCIe x1 SSD support) * The M.2 connector operates at up to x1 mode.
Dimensions
17.0cm x 17.0cm
H/W Monitoring
Voltage detection Temperature detection Fan speed detection
I/O Controller
iTE® I/O Controller Chip
Expansion Slots
1 x PCI Express x1 slot (The PCI Express x1 slot conforms to PCI Express 2.0 standard.) 1 x M.2 Socket 1 connector for an Intel® wireless module (CNVI) 1 x full size Mini PCIe connector (MINI_PCIE) (The Mini PCIe connector conforms to PCI Express 2.0 standard.)
Unique Features
Support for Xpress Install Support for @BIOS Support for APP Center * Available applications in APP Center may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications
Bundled Software
Norton® Internet Security (OEM version)
Onboard Graphics
Integrated in the SoC: 1 x D-Sub port, supporting a maximum resolution of 1920 x 1200@60 Hz 1 x LVDS connector supporting a maximum resolution of 1920 x 1200@60Hz 1 x HDMI 2.0 port, supporting a maximum resolution of 3840 x 2160@60 Hz Maximum shared memory of 512 MB
Operating System
Support for Windows 10 64-bit
Back Panel Connectors
1 x DC-In power connector 1 x HDMI2.0 port 1 x D-Sub port 4 x USB 3.1 Gen 1 ports 2 x RJ-45 ports 2 x audio jacks (Line In, Mic In)
Internal I/O Connectors
1 x 4-pin ATX 12V power connector 1 x CPU fan header 1 x system fan header 2 x SATA 6Gb/s connectors 1 x M.2 Socket 3 connector 1 x SATA power connector 1 x front panel header 1 x front panel audio header 1 x battery cable header 2 x USB 2.0/1.1 headers 6 x serial port headers 6 x serial port power select jumpers 1 x D-Sub header 1 x LVDS header 1 x LVDS drive voltage jumper (LCD_VCC) 1 x flat panel display header (FPD) 1 x flat panel display power select jumper (FPD_PWR) 1 x flat panel display switch header (MON_SW) 1 x backlight switch header (BL_SW) 1 x digital microphone header (DMIC_CON) 1 x speaker header (SPKR) 1 x buzzer header (SPEAKER) 1 x chassis intrusion jumper 1 x LPT/GPIO header (LPT_GPIO) 1 x LPT configuration jumper (LPT_SEL) 1 x GPIO power selection jumper (GPIO_PWRSEL) 1 x GPIO status configuration jumper (GPIO_SET) 1 x BIOS Select jumper (BIOS_SET) 1 x Clear CMOS jumper 1 x I2C 1 x SMBUS
