Support for 9th and 8th Generation Intel® Core™ i9 processors/Intel® Core™ i7 processors/Intel® Core™ i5 processors/Intel® Core™ i3 processors/Intel® Pentium® processors/Intel® Celeron® processors in the LGA1151 package (up to 65W) (Go to GIGABYTE's website for the latest CPU support list.) L3 cache varies with CPU (Please refer "CPU Support List" for more information.)
USB
Chipset: 1 x USB Type-C™ port, with USB 3.1 Gen 1 support 3 x USB 3.0/2.0 ports (2 ports on the back panel, 1 port onboard) 2 x USB 2.0/1.1 ports available through the internal USB header
BIOS
1 x 128 Mbit flash Use of licensed AMI UEFI BIOS PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
Memory
2 x DDR4 SO-DIMM sockets supporting up to 32 GB of system memory Dual channel memory architecture Support for DDR4 2400/2133 MHz memory modules (Please refer "Memory Support List" for more information.)
Remark
Due to different Linux support condition provided by chipset vendors, please download Linux driver from chipset vendors' website or 3rd party website.Most hardware/software vendors may no longer offer drivers to support Win9X/ME/2000/XP. If drivers are available from the vendors, we will update them on the GIGABYTE website.
Storage
Chipset: 2 x SATA 6Gb/s connectors 1 x M.2 connector (Socket 3, M key, type 2280 SATA/PCIe mode SSD support)
Dimensions
14.0cm x 14.7cm
H/W Monitoring
System voltage detection CPU/System temperature detection CPU/System fan fail warning CPU/System fan speed detection CPU/System fan speed control * Whether the fan speed control function is supported will depend on the cooler you install. CPU/System overheating warning
I/O Controller
iTE® I/O Controller Chip
Expansion Slots
1 x M.2 Socket 1 connector for the wireless communication module (M2_WIFI)
Unique Features
Support for APP Center * Available applications in APP Center may vary by motherboard model. Supported functions of each applicationmay also vary depending onmotherboard specifications. @BIOS Support for Q-Flash
Bundled Software
Norton® Internet Security (OEM version)
Onboard Graphics
Integrated Graphics Processor-Intel® HD Graphics support 1 x D-Sub port, supporting a maximum resolution of 1920x1200@60 Hz 1 x DisplayPort, supporting a maximum resolution of 4096x2304@60 Hz * Support for DisplayPort 1.2 version, HDCP 2.2, and HDR. 1 x HDMI port, supporting a maximum resolution of 4096x2160@24 Hz * Support for HDMI 2.0 version, HDCP 2.2, and HDR. Maximum shared memory of 1 GB
Operating System
Support for Windows 10 64-bit
Back Panel Connectors
1 x DC In power connector 1 x D-Sub port 1 x HDMI port 1 x DisplayPort 2 x USB 3.0/2.0 ports 1 x RJ-45 port
Operating Temperature
0°C to +50°C
Internal I/O Connectors
1 x CPU fan header 1 x system fan header 2 x SATA 6Gb/s connectors 1 x M.2 Socket 3 connector 1 x SATA power connector 1 x front panel header 1 x battery power cable connector 1 x USB 2.0/1.1 header 2 x serial port headers 1 x speaker header 1 x buzzer header 1 x Clear CMOS jumper 1 x chassis intrusion header 1 x USB 3.0/2.0 header 1 x USB Type-C™ port, with USB 3.1 Gen 1 support 1 x microphone jack 1 x headphone and microphone combo jack
