Support for 7th/6th Generation Intel® Core™ i7 processors/ Intel® Core™ i5 processors/ Intel® Core™ i3 processors/ Intel® Pentium® processors/ Intel® Celeron® processors in the LGA1151 package (up to 65W) * For 7th Generation Intel® Core™ processors support need to update the latest BIOS. * This motherboard supports 12V, 19V power adapters. When a 35W CPU is installed, it is recommended that a 95W power adapter be used. When a 65W CPU is installed, it is recommended that a 120W power adapter be used. L3 cache varies with CPU (Please refer "CPU Support List" for more information.)
USB
Chipset: 1 x USB Type-C™ port onboard, with USB 3.0 support 3 x USB 3.0/2.0 ports (2 ports on the back panel, 1 port onboard) 2 x USB 2.0/1.1 ports available through the internal USB header
BIOS
2 x 64 Mbit flash Use of licensed AMI UEFI BIOS Support for DualBIOS™ PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
Memory
2 x DDR4 SO-DIMM sockets supporting up to 32 GB of system memory * Due to a Windows 32-bit operating system limitation, when more than 4 GB of physical memory is installed, the actual memory size displayed will be less than the size of the physical memory installed. Dual channel memory architecture Support for DDR4 2400/2133 MHz memory modules (Please refer "Memory Support List" for more information.)
Remark
Due to different Linux support condition provided by chipset vendors, please download Linux driver from chipset vendors' website or 3rd party website.Most hardware/software vendors may no longer offer drivers to support Win9X/ME/2000/XP. If drivers are available from the vendors, we will update them on the GIGABYTE website.
Storage
Chipset: 2 x SATA 6Gb/s connectors 1 x M.2 connector (Socket 3, M key, type 2280 SATA SSD support)
Dimensions
14.0cm x 14.7cm
H/W Monitoring
System voltage detection CPU/System temperature detection CPU/System fan fail warning CPU/System fan speed detection CPU/System fan speed control * Whether the fan speed control function is supported will depend on the cooler you install. CPU/System overheating warning
I/O Controller
iTE® I/O Controller Chip
Expansion Slots
1 x M.2 Socket 1 connector for the wireless communication module (M2_WIFI) * After installing the wireless module, use the supplied screws to fasten it in place.
Unique Features
Support for APP Center * Available applications in APP Center may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications. @BIOS Support for Q-Flash
Bundled Software
Norton® Internet Security (OEM version)
Onboard Graphics
Integrated Graphics Processor-Intel® HD Graphics support 1 x D-Sub port, supporting a maximum resolution of 1920x1200@60 Hz 1 x DisplayPort, supporting a maximum resolution of 4096x2304@60 Hz * Support for DisplayPort 1.2 version. 1 x HDMI port, supporting a maximum resolution of 4096x2160@24 Hz * Support for HDMI 1.4 version. Support for up to 2 displays at the same time Maximum shared memory of 512 MB
Operating System
Windows® 10 64-bit (for 7th Generation Intel® Processors) Windows® 10 64-bit / Windows® 8.1 64-bit / Windows® 7 32-bit / 64-bits (for 6th Generation Intel® Processors) * Please download the "Windows USB Installation Tool" from GIGABYTE's website and install it before installing Windows 7.
Back Panel Connectors
1 x DC In power connector 1 x D-Sub port 1 x HDMI port 1 x DisplayPort 2 x USB 3.0/2.0 ports 1 x RJ-45 port
Operating Temperature
0°C to +50°C
Internal I/O Connectors
1 x CPU fan header 1 x system fan header 2 x SATA 6Gb/s connectors 1 x M.2 connector 1 x SATA power connector 1 x front panel header 1 x battery cable header 1 x USB 2.0/1.1 header 1 x serial port header 1 x serial port power select jumper 1 x speaker header 1 x buzzer header 1 x Clear CMOS jumper 1 x chassis intrusion header 1 x USB 3.0/2.0 port 1 x USB Type-C™ port 1 x microphone jack 1 x headphone and microphone combo jack
