North Bridge: Intel® 945GC Express South Bridge: Intel® ICH7
Form factor
Mini-ITX
Max memory
2 GB
Audio codec
ALC662
SATA ports
2
Full vendor specifications · 17
CPU
Built in with an Intel® Atom™ 230 CPU (1.6GHz) 512K L2 cache
USB
Integrated in the South Bridge Up to 8 USB 2.0/1.1 ports (4 on the back panel, 4 via the USB brackets connected to the internal USB headers)
BIOS
1 x 4 Mbit flash Use of licensed AWARD BIOS PnP 1.0a, DMI 2.0, SM BIOS 2.4, ACPI 1.0b
Memory
1 x 1.8V DDR2 DIMM socket supporting up to 2 GB of system memory Support for DDR2 533/400 MHz memory module (Go to GIGABYTE's website for the latest memory support list.)
Remark
Due to different Linux support condition provided by chipset vendors, please download Linux driver from chipset vendors' website or 3rd party website.Most hardware/software vendors may no longer offer drivers to support Win9X/ME/2000/XP SP1/SP2. If drivers are available from the vendors, we will update them on the GIGABYTE website.
Storage
South Bridge: 1 x IDE connector supporting ATA-100/66/33 and up to 2 IDE devices 2 x SATA 3Gb/s connectors supporting up to 2 SATA 3Gb/s devices
Dimensions
17.0cm x 17.0cm
Front Side Bus
533 MHz FSB
H/W Monitoring
System voltage detection CPU temperature detection CPU/North Bridge/System fan speed detection CPU fan speed control
I/O Controller
iTE IT8718 chip
Expansion Slots
1 x PCI slot
Unique Features
Support for @BIOS Support for Download Center Support for Q-Flash Support for EasyTune Support for Xpress Install Support for Xpress Recovery2 Support for Virtual Dual BIOS
Bundled Software
Norton Internet Security (OEM version)
Onboard Graphics
Integrated in the North Bridge
Operating System
Support for Microsoft® Windows® XP
Back Panel Connectors
1 x PS/2 keyboard port 1 x PS/2 mouse port 1 x parallel port 1 x serial port 1 x D-Sub port 4 x USB 2.0/1.1 ports 1 x RJ-45 port 3 x audio jacks (Line In/Line Out/Microphone)
Internal I/O Connectors
1 x 20-pin ATX main power connector 1 x 4-pin ATX 12V power connector 1 x IDE connector 2 x SATA 3Gb/s connectors 1 x CPU fan header 1 x system fan header 1 x front panel header 1 x front panel audio header 2 x USB 2.0/1.1 headers 1 x chassis intrusion header 1 x power LED header
