Built in with an AMD E-350 Dual-Core processor Built in with an AMD Radeon HD 6310 (DirectX 11) graphics core
USB
FCH: Up to 8 USB 2.0/1.1 ports (4 on the back panel, 4 via the USB brackets connected to the internal USB headers) Renasas D720200 chip: Up to 2 USB 3.0 ports on the back panel * USB 3.0 10x performance is a maximum theoretical value. Actual performance may vary by system configuration.
BIOS
2 x 16 Mbit flash Use of licensed AWARD BIOS Support for DualBIOS™ PnP 1.0a, DMI 2.0, SM BIOS 2.4, ACPI 1.0b
Note
* GIGABYTE reserves the right to make any changes to the product specifications and product-related information without prior notice.
Memory
2 x 1.5V DDR3 DIMM sockets supporting up to 8 GB of system memory * Due to Windows 32-bit operating system limitation, when more than 4 GB of physical memory is installed, the actual memory size displayed will be less than 4 GB. Single channel memory architecture Support for DDR3 1333(OC)/1066 MHz memory modules
Remark
Due to different Linux support condition provided by chipset vendors, please download Linux driver from chipset vendors' website or 3rd party website. Most hardware/software vendors may no longer offer drivers to support Win9X/ME/2000/XP SP1/SP2. If drivers are available from the vendors, we will update them on the GIGABYTE website. Minimum 200 Watts power supply is suggested on this model.
Storage
FCH: 4 x SATA 6Gb/s connectors supporting up to 4 SATA 6Gb/s devices * SATA3 2x performance are maximum theoretical values. Actual performance may vary by system configuration.
Dimensions
17.0cm x 17.0cm
H/W Monitoring
System voltage detection CPU/System temperature detection CPU/System fan speed detection
I/O Controller
ITE IT8720 chip
Expansion Slots
1 x PCI Express x16 slot, running at x4 (The PCIEX4 slot conforms to PCI Express 2.0 standard.)
Unique Features
Support for @BIOS Support for Q-Flash Support for Xpress BIOS Rescue Support for Download Center Support for Xpress Install Support for Xpress Recovery2 Support for EasyTune * Available functions in EasyTune may differ by motherboard model. Support for Smart Recovery Support for Auto Green Support for On/Off Charge Support for Q-Share
Bundled Software
Norton Internet Security (OEM version)
Onboard Graphics
Integrated in the APU: 1 x D-Sub port 1 x DVI-D port, supporting a maximum resolution of 1920x1200 * The DVI-D port does not support D-Sub connector by adapter. 1 x HDMI port, supporting a maximum resolution of 1920x1200 * For configuring screen resolution, please refer the user manual- Chapter 1 Hardware Installation of Back Panel Connectors section.
Operating System
Support for Microsoft Windows 7/ Vista/ XP
Back Panel Connectors
1 x PS/2 keyboard/ mouse port 1 x D-Sub port 1 x DVI-D port 1 x HDMI port 1 x optical S/PDIF Out connector 4 x USB 2.0/1.1 ports 2 x USB 3.0/2.0 ports 1 x RJ-45 port 6 x audio jacks (Center/Subwoofer Speaker Out/Rear Speaker Out/Side Speaker Out/Line In/Line Out/Microphone)
Internal I/O Connectors
1 x 24-pin ATX main power connector 1 x 4-pin ATX 12V power connector 4 x SATA 6Gb/s connectors 1 x CPU fan header 1 x system fan header 1 x front panel header 1 x front panel audio header 1 x S/PDIF Out header 2 x USB 2.0/1.1 headers 1 x debug card header * This port is mainly used by repair technicians for debugging and problem diagnosis. 1 x chassis instrusion header 1 x power LED header 1 x clearing CMOS jumper
